WAGO 750 Series Analog Input And Output Module - 750-530

WAGO 750 Series Analog Input And Output Module - 750-530

Wago fieldbus decentralized peripheral analog input and output module. This module has a supply vo...

Best current price£55.61from RS Components Ltd- UK

Best offers

Shopping.co.uk recommended and popular offers

Lowest priceMost popular
RS Components Ltd- UK£55.61Visit shop

Wago - PLC I/O Module for use with 750 Series, 100 x 12 x 64 mm, Digital, TM5, 24 V dc

Visit shop

All Offers

6 offers from £55.61 - £217.70

View price history by clicking the chart icon.

RS Components Ltd- UKWago - PLC I/O Module for use with 750 Series, 100 x 12 x 64 mm, Digital, TM5, 24 V dc
Free delivery in 1–3 days
£55.61
Visit shop
Tameson UKWago Fieldbus, Decentralized Peripheral - Analog Input And Output Module - 750-530
Free delivery in 1–3 days
£89.90
Visit shop
eBayModule 8DO 24V DC 0.5A 750-530
£11.00 delivery
£199.47
Visit shop

Used Offers

3 offers from £36.37 - £58.82

View price history by clicking the chart icon.

eBayWago Digital Output 750-530 8 Channel Module Unit DC 24V Light Gray
£29.02 delivery
£36.37
Visit shop

Product Information

Full details

The WAGO 750-530 is a fieldbus module designed for industrial automation applications, offering 8 digital output channels for controlling connected loads. It is ideal for systems requiring reliable switching and isolation between field and system levels. A key benefit is its compact size and short-circuit protection on all outputs, though users should note its IP20 rating means it's not suitable for wet environments without additional enclosure.

All features

BrandWAGO

Extended Product Information

FAQs

What is the maximum current rating per channel?

The module supports a maximum of 0.5 A per channel.

Can this module be used in wet environments?

No, the module has an IP20 rating, meaning it is protected against solid objects larger than 12.5mm but offers no protection against water. It should be installed in a suitable enclosure if exposed to moisture.

What type of supply voltage does this module require?

The module requires a 24 V DC supply voltage.

What does the 'Isolation: 0.5 kV' specification mean?

It means the module provides 0.5 kilovolts of electrical isolation between the field side (connected loads/actuators) and the system side (control system/PLC), helping to protect the control system from voltage spikes or ground loops.

Is this module suitable for hazardous locations?

Yes, it features explosion protection for ATEX gas-Ex security, making it suitable for certain hazardous environments.

How are the outputs switched?

The connected loads are switched via digital output signals from the control system.

What are the physical dimensions of the module?

The module measures 12 mm (width) x 100 mm (depth) x 67.8 mm (height).

Troubleshooting

No output signal from channels

Verify 24V DC supply voltage is present and correct. Check wiring connections to the control system and loads. Ensure the control system is sending the correct digital signal.

Module not recognized by fieldbus system

Confirm correct installation on the carrier rail and proper bus connection. Check fieldbus addressing and configuration settings in the control system software.

Overheating or intermittent operation

Ensure ventilation slots are unobstructed. Check if the connected load exceeds the 0.5A per channel limit. Verify ambient temperature is within operational limits.

Short circuit detected on an output

Disconnect the load from the affected output. Inspect the load and wiring for shorts. Once the fault is cleared, reset the module or control system to resume operation.

Pros and Cons

Pros

  • Space-saving 12mm width allows for more modules in limited cabinet space.
  • Integrated short-circuit protection on all outputs increases operational safety.
  • Electrical isolation enhances system robustness and protects sensitive control components.
  • ATEX certification enables deployment in hazardous industrial zones.
  • Easy mounting on standard DIN carrier rails simplifies installation.

Cons

  • IP20 rating requires protection from dust and moisture in harsh environments.
  • Limited to digital output functions; does not support analog signals.
  • Requires a 24V DC supply voltage, which might necessitate specific power distribution.
  • Dimensions are specific, requiring consideration for cabinet layout.

Setup, Compatibility & Care

Setup:

  1. Mount the module onto a standard DIN carrier rail (35mm).
  2. Connect the 24V DC supply voltage to the appropriate terminals.
  3. Connect the digital output signals from your control system to the module's input terminals.
  4. Wire the actuators or loads to the output terminals.
  5. Ensure field and system connections are correctly made for isolation.

Compatibility:

  • The WAGO 750-530 is part of the WAGO I/O system 750, designed to integrate seamlessly with other modules in this series.
  • Compatible with PLCs and control systems that support standard digital output signaling.
  • Requires a 24V DC power supply.

Care:

  • The module has an IP20 rating; avoid exposure to moisture, corrosive substances, and excessive dust. Use in a suitable enclosure if necessary.
  • Keep ventilation slots clear to prevent overheating.
  • Periodically check all electrical connections for tightness.
